The FIXAR 007 NG is a fixed-wing, vertical takeoff and landing (VTOL) unmanned aerial vehicle (UAV) designed for tactical and industrial missions in the field. With rapid deployment and autonomous navigation, it is specifically designed for a variety of field operations. A 1.6 m (5.3 ft) wingspan, a flight time of up to 70 minutes, and a payload capacity of up to 2 kg (4.4 lb) provide an optimal balance of range, efficiency, and reliability.
Characteristics
Number of rotors: 4;
Maximum takeoff weight: 7 kg;
Payload, up to: 2 kg;
Wingspan: 1.6 m;
Body length: 0.9 m;
Maximum flight duration: up to 70 min;
Maximum flight range: up to 55 km;
Maximum flight altitude (ASL*): 6115 m;
Maximum horizontal flight speed**: 24 m/s (86 km/h);
Operating temperature range: from −30 °C to +60 °C;
Software: FIXAR xGroundControl;
Autopilot: FIXAR autopilot 2.0;
Telemetry transmission protocol: XLink;
Ability to operate in conditions of geomagnetic interference
Possibility of flight in conditions without GPS: Basic mode - IMU-based flight for signal jamming scenarios; Advanced mode - computer vision and AI system for navigation in GPS-less environments;
Intelligent autopilot and navigation: real-time terrain tracking and following, obstacle avoidance;
Flight modes: autonomous; manual; altitude hold; stabilization; position hold (optional); level cruise;
Supported hand control devices: 1. USB joystick 2. RC transmitter 3. Point-and-click control;
Power type: electric;
Battery: Li-Ion, 25 V, 27 Ah;
* ASL — altitude above sea level;
** Maximum horizontal flight speed is the maximum speed of the UAV in stable horizontal flight without gaining or losing altitude;
***Cruising Speed is the recommended constant speed for the most efficient and stable long-term missions.
FIXAR 007NG
The FIXAR 007 NG is a compact and field-proven unmanned aerial vehicle for everyday tactical and commercial operations.
Description
The FIXAR 007 NG is a fixed-wing, vertical takeoff and landing (VTOL) unmanned aerial vehicle (UAV) designed for tactical and industrial missions in the field. With rapid deployment and autonomous navigation, it is specifically designed for a variety of field operations. A 1.6 m (5.3 ft) wingspan, a flight time of up to 70 minutes, and a payload capacity of up to 2 kg (4.4 lb) provide an optimal balance of range, efficiency, and reliability.
Characteristics
Number of rotors: 4;
Maximum takeoff weight: 7 kg;
Payload, up to: 2 kg;
Wingspan: 1.6 m;
Body length: 0.9 m;
Maximum flight duration: up to 70 min;
Maximum flight range: up to 55 km;
Maximum flight altitude (ASL*): 6115 m;
Maximum horizontal flight speed**: 24 m/s (86 km/h);
Cruising speed***: 18 m/s (65 km/h);
Maximum wind resistance: 15 m/s (54 km/h);
Deployment time: up to 5 minutes;
BVLOS Readiness: Remote ID; ADS-B In/Out (optional);
Protection level: IP54;
Operating temperature range: from −30 °C to +60 °C;
Software: FIXAR xGroundControl;
Autopilot: FIXAR autopilot 2.0;
Telemetry transmission protocol: XLink;
Ability to operate in conditions of geomagnetic interference
Possibility of flight in conditions without GPS: Basic mode - IMU-based flight for signal jamming scenarios; Advanced mode - computer vision and AI system for navigation in GPS-less environments;
Intelligent autopilot and navigation: real-time terrain tracking and following, obstacle avoidance;
Flight modes: autonomous; manual; altitude hold; stabilization; position hold (optional); level cruise;
Supported hand control devices: 1. USB joystick 2. RC transmitter 3. Point-and-click control;
Power type: electric;
Battery: Li-Ion, 25 V, 27 Ah;
* ASL — altitude above sea level;
** Maximum horizontal flight speed is the maximum speed of the UAV in stable horizontal flight without gaining or losing altitude;
***Cruising Speed is the recommended constant speed for the most efficient and stable long-term missions.
