The FIXAR 025 is an all-electric vertical takeoff and landing (VTOL) unmanned aerial vehicle (UAV) designed for demanding field missions, combining intelligent autonomy with a robust and reliable design.
The FIXAR 025 is a fixed-wing, vertical takeoff and landing (VTOL) unmanned aerial vehicle (UAV) designed for endurance and performance. It offers up to 210 minutes (3.5 hours) of flight time, a range of 300 km (186 miles), and a payload of up to 10 kg (22 lbs). It provides extended autonomy for challenging missions. With resistance to interference and signal spoofing, an intelligent autopilot and navigation, and a construction made from aircraft-grade materials, the FIXAR 025 is designed to operate in real-world conditions.
Characteristics
Number of rotors: 4;
Maximum takeoff weight: 24.9 kg;
Payload, up to: 10 kg;
Multiple payload support: simultaneous integration is possible;
Wingspan: 2.9 m;
Body length: 2.4 m;
Maximum flight duration: up to 210 min;
Maximum flight range: up to 300 km;
Maximum flight altitude (ASL*): 6115 m;
Maximum horizontal flight speed**: 20 m/s (72 km/h);
Operating temperature range: from −30 °C to +60 °C;
Software: FIXAR xGroundControl;
Autopilot: FIXAR autopilot 2.0;
Telemetry transmission protocol: XLink;
Ability to operate in conditions of geomagnetic interference
Possibility of flight in conditions without GPS: Basic mode – IMU-based flight for signal jamming scenarios; Advanced mode – computer vision and AI system for navigation in GPS-less environments;
Intelligent autopilot and navigation: Real-time terrain tracking and following, avoiding collisions with ground obstacles;
Flight modes: autonomous; manual; altitude hold; stabilization; position hold (optional); level cruise;
Supported hand control devices: 1. USB joystick 2. RC transmitter 3. Point-and-click control;
Power type: electric;
Battery: Li-Ion, 44.4 V, 54 Ah (12S2P);
* ASL — altitude above sea level;
** Maximum horizontal flight speed is the maximum speed of the UAV in stable horizontal flight without gaining or losing altitude;
***Cruising Speed is the recommended constant speed for the most efficient and stable long-term missions.
FIXAR 025
The FIXAR 025 is an all-electric vertical takeoff and landing (VTOL) unmanned aerial vehicle (UAV) designed for demanding field missions, combining intelligent autonomy with a robust and reliable design.
Description
The FIXAR 025 is a fixed-wing, vertical takeoff and landing (VTOL) unmanned aerial vehicle (UAV) designed for endurance and performance. It offers up to 210 minutes (3.5 hours) of flight time, a range of 300 km (186 miles), and a payload of up to 10 kg (22 lbs). It provides extended autonomy for challenging missions. With resistance to interference and signal spoofing, an intelligent autopilot and navigation, and a construction made from aircraft-grade materials, the FIXAR 025 is designed to operate in real-world conditions.
Characteristics
Number of rotors: 4;
Maximum takeoff weight: 24.9 kg;
Payload, up to: 10 kg;
Multiple payload support: simultaneous integration is possible;
Wingspan: 2.9 m;
Body length: 2.4 m;
Maximum flight duration: up to 210 min;
Maximum flight range: up to 300 km;
Maximum flight altitude (ASL*): 6115 m;
Maximum horizontal flight speed**: 20 m/s (72 km/h);
Cruising speed***: 16 m/s (58 km/h);
Maximum wind resistance: 15 m/s (54 km/h);
Deployment time: up to 10 min;
BVLOS Readiness: Remote ID; ADS-B In/Out (optional);
Protection level: IP54;
Operating temperature range: from −30 °C to +60 °C;
Software: FIXAR xGroundControl;
Autopilot: FIXAR autopilot 2.0;
Telemetry transmission protocol: XLink;
Ability to operate in conditions of geomagnetic interference
Possibility of flight in conditions without GPS: Basic mode – IMU-based flight for signal jamming scenarios; Advanced mode – computer vision and AI system for navigation in GPS-less environments;
Intelligent autopilot and navigation: Real-time terrain tracking and following, avoiding collisions with ground obstacles;
Flight modes: autonomous; manual; altitude hold; stabilization; position hold (optional); level cruise;
Supported hand control devices: 1. USB joystick 2. RC transmitter 3. Point-and-click control;
Power type: electric;
Battery: Li-Ion, 44.4 V, 54 Ah (12S2P);
* ASL — altitude above sea level;
** Maximum horizontal flight speed is the maximum speed of the UAV in stable horizontal flight without gaining or losing altitude;
***Cruising Speed is the recommended constant speed for the most efficient and stable long-term missions.
